کابل شبکه NC-Cuprum 6SFTPI-LSZH KDT
کابل شبکه NC-Cuprum 6SFTPI-LSZH KDT سری کوپریوم
| NC-Cuprum 6SFTPI | |
| Conductor | |
| Size | 23 AWG |
| Design Type | Spacer / Copper Wires / 1 Jacket/ Shield/Foil |
| Diameter (mm) | 0.5 ± 0.55 |
| Insulation | |
| Type | SFTP-Indoor |
| Cable Diameter | Nom.5.5 ± 0.5 mm |
| Jacket Thickness | Nominal Thickness = 0.56 mm |
| Shielding | Aluminium / Polyester Foil |
| Physical | |
| 1. Cold Bend Test | -30 ± 2°C X 4hrs no crack |
| 2. Dielectric strength | AC 1.7KV for 2s |
| 3.Insulation | Before Aging | After Aging |
| Min Tensile Strength (psi) | 2400 | 75% before aging (100°C X 48hours) |
| Min elongation (%) | 300 | 75% before aging (100°C X 48hours) |
| Jacket | |
| Min Bending Radius | 50 mm |
| Installation Temperature | -20°C to +65°C |
| Jacket | |
| Type | Low Smoke Zero Halogen(LSZH) |
| Overall Diameter | 8.1 ± 0.3 mm |
